Brass Single Jet Dry Type Water Meters

SKU: 09002

SKU 09002 Category Water Meters Tags Agricultural, Building & Interior Spaces, Industrial

Full or partial flow control.
Reliable sealing when fully closed.
Not ideal for throttling since partial openings may cause wear on the gate.
Working Pressure: 230PSI, PN16
End: NPT, BSP
Accuracy: R80, R100, R160
Temperature: Cold, Hot
Material: Brass HPB57

Spec

Clear

Add to quote

Contents

1 Why Choose Our Brass Gate Valves?

2 Datasheet

2.1 Technical Data

2.2 Overall Dimensions and Weight

Our Brass Gate Valves are precision-engineered to provide efficient on/off control of fluid flow within pipelines. Constructed from high-quality brass, these valves deliver exceptional resistance to corrosion and wear, ensuring dependable operation even in demanding environments. Whether you’re handling water, gas, or low-pressure steam, our gate valves deliver long-lasting performance with minimal upkeep.

Why Choose Our Brass Gate Valves?

Engineered for stability and built to last, our brass gate valves offer a smart solution for professionals seeking durable, cost-effective flow control. With their universal compatibility and minimal maintenance requirements, they are a trusted choice for a wide range of fluid handling systems.

Datasheet

Technical Data

Nominal Size DN (mm)	Class of Measurement	Overload Flow-rate qₛ (m³/h)	Permanent Flow-rate qₚ (m³/h)	Transitional Flow-rate qₜ (l/h)	Minimum Flow-rate qₘᵢₙ (l/h)
15 (13)	B	3	1.5	120	30
20	B	5	2.5	200	50
25	B	7	3.5	280	70
32	B	12	6	480	120F8
40	B	20	10	800	200

Overall Dimensions and Weight

Size (mm)	Length (mm) L	Width (mm) W	Height (mm) H	Connecting Thread D	Weight (kg)
13	110	77	80	G ¾” B	0.57F15
20	130	77	80	G 1″ B	0.67
25	160	77	80	G 1¼” B	0.91
32	160	101	120	G 1½” B	1.41
40	200	101	120	G 2″ B	1.65

Model No.	Size	Work Pressure	End	Accuracy	Temperature	Material	MOQ
0900202222	1/2″	230PSI	NPT	R80	Cold	Brass HPB57	300
0900202242	1/2″	230PSI	NPT	R100	Cold	Brass HPB57	300
0900202262	1/2″	230PSI	NPT	R160	Cold	Brass HPB57	300
0900202224	1/2″	230PSI	NPT	R80	Hot	Brass HPB57	300
0900202244	1/2″	230PSI	NPT	R100	Hot	Brass HPB57	300
0900202264	1/2″	230PSI	NPT	R160	Hot	Brass HPB57	300
0900204222	3/4″	230PSI	NPT	R80	Cold	Brass HPB57	200
0900204242	3/4″	230PSI	NPT	R100	Cold	Brass HPB57	200
0900204262	3/4″	230PSI	NPT	R160	Cold	Brass HPB57	200
0900204224	3/4″	230PSI	NPT	R80	Hot	Brass HPB57	200
0900204244	3/4″	230PSI	NPT	R100	Hot	Brass HPB57	200
0900204264	3/4″	230PSI	NPT	R160	Hot	Brass HPB57	200
0900206422	DN15	PN16	BSP	R80	Cold	Brass HPB57	300
0900206442	DN15	PN16	BSP	R100	Cold	Brass HPB57	300
0900206462	DN15	PN16	BSP	R160	Cold	Brass HPB57	300
0900206424	DN15	PN16	BSP	R80	Hot	Brass HPB57	300
0900206444	DN15	PN16	BSP	R100	Hot	Brass HPB57	300
0900206464	DN15	PN16	BSP	R160	Hot	Brass HPB57	300
0900208422	DN20	PN16	BSP	R80	Cold	Brass HPB57	200
0900208442	DN20	PN16	BSP	R100	Cold	Brass HPB57	200
0900208462	DN20	PN16	BSP	R160	Cold	Brass HPB57	200
0900208424	DN20	PN16	BSP	R80	Hot	Brass HPB57	200
0900208444	DN20	PN16	BSP	R100	Hot	Brass HPB57	200
0900208464	DN20	PN16	BSP	R160	Hot	Brass HPB57	200

Sample Policy

We are happy to provide product samples for customers to evaluate quality or conduct testing. The process typically begins with a quotation based on the customer’s specifications.

If the pricing is acceptable, we can offer samples either free of charge or at a cost depending on the product type and availability. Shipping fees are borne by the customer.

Order Process

After confirming the product requirements and other details with the customer, we will issue a Sales Confirmation for approval. Once confirmed, the customer is required to pay a 30% deposit to proceed with production.

When mass production is completed and the goods pass inspection, the customer must pay the remaining 70% balance before shipment is arranged.

Frequently Asked Questions (FAQ)

A. How can I request a quote?

Please provide a detailed inquiry sheet including product specifications, materials, quantities, and any special requirements. We will offer a quotation based on your request.

B. What are your quotation terms?

Our quotations are typically based on FOB terms. However, we can also offer CFR, CIF, or other Incoterms upon request.

C. What is your Minimum Order Quantity (MOQ)?

We operate on a made-to-order basis and do not hold stock.
Our standard MOQ is USD 15,000. Depending on the order composition, we may offer flexibility in certain cases.

D. What are your payment terms?

By T/T – 30% down payment upon order confirmation, and 70% balance before shipment.

E. What is your lead time?

Our general lead time ranges from 30 to 45 days, depending on the order complexity and production schedule.
For more complex orders or during peak seasons, it may extend to 60–90 days.
